| Sample Types |
Inorganic, dry samples; any form or shape |
Metals, alloys, powders, ceramics |
| Sample Dimensions |
Up to approx. 8 × 8 mm cross section |
Pieces, chips, pins, granules; different sample ports available |
| Analyzed Elements |
Oxygen, Nitrogen, Hydrogen (O, N, H) |
Single or dual element configurations (O, N, H, ON, OH) |
| Oxygen Detector |
Non-dispersive IR (NDIR) for CO |
Multiple ranges, reference beam, drift-free |
| N & H Detector |
Dual-channel Thermal Conductivity Detector (TCD) |
Separate reference channel, adjustable gain, sub-ppm/ppb range |
| Furnace |
Water-cooled electrode furnace with FusionControl |
High temperature operation (> 3000 °C) with precise temperature control |
| SampleCare™ – EZDrive |
Electronic motion module for lower electrode movement |
No compressed air required; automatic, torque-limited adjustment |
| SampleCare™ – Sample Port |
Rotating, water-cooled sample port |
Shields sample from heat, allows capsule-free measurement of grains |
| SampleCare™ – Particle Filtering |
High-capacity dust trap + in-line particle filter |
Stable results, reduced maintenance, component protection |
| Cooling Water |
Approx. 4 L/min at 3 bar |
Tap water or chiller; solenoid valve for water-saving design |
| Carrier Gas |
Ar or He for O/N; N2 for H |
Purity 99.995% (99.999% for trace analysis) |
| Calibration |
Single- and multi-point calibration |
Advanced weighting algorithm with range merging |
| Reagents |
Magnesium perchlorate, NaOH on support, CuO (N-model), Schuetze reagent (H-model) |
Depending on configuration |
| Power Supply |
400–480 VAC, 50–60 Hz, 32 A, 7 kVA (option: 230 VAC, 64 A) |
Compatible with worldwide mains configurations |
| Dimensions & Weight |
Approx. 71 × 66 × 78 cm (W × D × H), ~145 kg |
Compact footprint, easy maintenance access |
