| Analyzer Design |
Three-Quadrupole (Q0: Quadrupole Ion Deflector, Q1: Universal Cell with 3 gas channels, Q2: Transmission Analyzer Quadrupole) :contentReference[oaicite:1]{index=1} |
Superior interference removal, flexible collision/reaction modes :contentReference[oaicite:2]{index=2} |
| Triple Cone Interface with OmniRing |
Wide-aperture, 3-stage vacuum pumping, improved ion focusing and low background equivalent concentrations (BECs) :contentReference[oaicite:3]{index=3} |
Minimizes cone clogging and routine maintenance :contentReference[oaicite:4]{index=4} |
| Dynamic Range / Detector Range |
< 0.1 cps to > 10⁹ cps; up to 10¹⁴ orders with EDR option :contentReference[oaicite:5]{index=5} |
Handles both ultra-trace and higher concentration samples in a single run :contentReference[oaicite:6]{index=6} |
| All Matrix Solution (AMS) / Sample Dilution |
Online aerosol dilution up to 200×; tolerates high TDS matrices (up to ~35 %) :contentReference[oaicite:7]{index=7} |
Reduces sample prep, improves uptime in tough matrices :contentReference[oaicite:8]{index=8} |
| Plasma / RF Source |
LumiCoil™ RF coil, solid-state 34 MHz generator, no water cooling needed; fast power switching (< 50 ns) :contentReference[oaicite:9]{index=9} |
Lower cost of ownership, enhanced performance in organic/cold plasma conditions :contentReference[oaicite:10]{index=10} |
| Dimensions & Weight |
Width ~81 cm; Depth ~72 cm; Height ~73 cm; Weight ~150 kg :contentReference[oaicite:11]{index=11} |
Compact footprint for lab setting :contentReference[oaicite:12]{index=12} |
| Power Requirements |
230 V AC, 50/60 Hz :contentReference[oaicite:13]{index=13} |
Standard lab power supply :contentReference[oaicite:14]{index=14} |
