| Sensor Pixel Sizes |
6.25 µm, 25 µm, 50 µm |
Choice between speed and spatial resolution |
| Spectral Range (Mid-IR) |
~ 7800 – 600 cm⁻¹ |
Extended range with optional configurations |
| Spectral Resolution |
0.5 cm⁻¹ (standard), 0.25 cm⁻¹ (optional) |
High-resolution spectral analysis |
| Spatial Resolution |
Down to ~ 6.25 µm |
Can be reduced with ATR imaging |
| Detector Options |
MCT Single Element; Linear Array; InGaAs NIR |
Flexible based on application |
| Sampling Modes |
Transmission, Reflection, Imaging ATR |
Switchable without complex adjustments |
| Sample Stage Area |
Large automated XYZ stage |
Ideal for imaging large samples |
| Unattended Operation |
Yes |
Supports overnight/long unattended runs |
| Software |
SpectrumIMAGE (AI-enabled) |
ROI selection, visualization, processing |
| Compliance |
GMP, FDA 21 CFR Part 11, USP/EP/JP |
For regulated industries |
| Dimensions (H × W × D) |
70 × 80 × 100 cm |
Compact for advanced labs |
| Weight |
~ 32–60 kg (config-dependent) |
Standard lab footprint |
| Operating Conditions |
10–35 °C, humidity controlled |
Standard laboratory environment |
