| Elemental Range |
Na, Mg, P, S, Cl, K, Ca, and ionic salts |
Optimized for pharmaceutical & biopharma analysis |
| Analysis Method |
Energy Dispersive XRF (EDXRF) |
Rapid, non-destructive XRF analysis |
| X-ray Tube |
Ag anode, 6–50 kV, up to 500 µA, 5 W max |
Dynamic current adjustment for optimal sensitivity |
| Detector |
Large Area Drift Detector |
High sensitivity for accurate ionic salt identification |
| Spot Size |
8 mm collimation |
Standard aperture for powders |
| Sample Types |
Solids, powders with minimal prep |
Raw material verification in pharma |
| Analysis Time |
< 30 seconds |
Fast results for high-throughput labs |
| Data Storage |
512 MB RAM / 16 GB storage |
Up to 130,000 readings with spectra & images |
| Software |
Integrated Thermo Scientific with 21 CFR Part 11 compliance |
Secure data management & electronic signatures |
| Connectivity |
Wi-Fi, USB, Bluetooth |
Wireless data transfer & barcode reader support |
| Cameras |
Macro & Micro CCD cameras |
Document sample & spot location |
| Weight & Dimensions |
5.8 lb (2.6 kg); 12 × 12 × 8 in (30.5 cm cube) |
Lightweight & compact design |
| IP Rating |
IP54 |
Dust and splash resistant |
| Battery |
12 V Li-ion, Hot-swap |
Continuous operation in the field |
| Regulatory Compliance |
21 CFR Part 11, EN 61010, EN 55011, EN 61326, RoHS |
Meets pharma & international safety standards |
