| Optical System |
Single or Double Beam (software selectable); Fiber-optic light path |
High stability and optical efficiency |
| Wavelength Range / Resolution |
180–900 nm; 0.2 nm resolution (Czerny-Turner) |
Covers all AAS elements |
| Lamp Configuration |
8-position auto lamp turret; supports HCL and EDL lamps |
Automatic lamp selection and alignment |
| Detector |
Peltier-cooled Photomultiplier Tube (PMT) |
Low noise, stable signal |
| Flame Atomizer |
Solid Titanium Burner (5 cm, 10 cm, or 3-slot) |
Corrosion-resistant, tool-free adjustment |
| Nebulizer |
Stainless Steel or High-Sensitivity HF-resistant |
Durable for corrosive matrices |
| Spray Chamber |
Ryton® or PTFE, corrosion-resistant |
Minimizes memory effects |
| Furnace System |
Transversely Heated Graphite Atomizer (THGA); Deuterium or Zeeman background correction |
STPF technology ensures accuracy |
| Autosampler |
AS 900, 148 samples, random access |
Fully automated sampling |
| Gas Controls |
Fuel: 0.5–4.0 L/min (0.1 steps); Oxidant: 2.0–15.0 L/min (0.1 steps) |
Electronic mass flow control |
| Dimensions & Weight |
95 × 68 × 73 cm; ~112 kg |
Compact bench-top footprint |
| Power Requirements |
100–240 V, 50/60 Hz, 300 VA |
Energy-efficient operation |
