| Optical System |
Single or Double Beam (software selectable) |
Flexibility for precision and background correction |
| Wavelength Range / Resolution |
180–900 nm; 0.2 nm resolution (Czerny-Turner) |
Covers all key AAS elements |
| Lamp Types |
Hollow Cathode Lamps (HCL), Electrodeless Discharge Lamps (EDL) |
EDL for higher sensitivity and lifetime |
| Detector |
Peltier-cooled Photomultiplier Tube |
Low noise, stable signal |
| Burner Head |
Titanium, corrosion-resistant, 10 cm standard; adjustable without tools |
Optional 5 cm and multi-slot heads |
| Nebulizer |
Stainless Steel, HF-resistant |
Durable for corrosive samples |
| Spray Chamber |
Ryton® or PTFE, corrosion-resistant |
Minimizes memory effects |
| Flame Types |
Air/Acetylene, N2O/Acetylene |
Supports high-temperature flames |
| Gas Controls |
Fuel: 0.5–4.0 L/min (0.1 L/min steps); Oxidant: 2.0–15.0 L/min (0.1 L/min steps) |
Precise electronic mass flow control |
| Sample Introduction |
3-channel Peristaltic Pump; 0.5–5 mL/min uptake |
Stable and consistent delivery |
| Dimensions & Weight |
94 × 68 × 68 cm; ~90 kg |
Compact bench-top design |
| Power Requirements |
100–240 V, 50/60 Hz, 300 VA |
Energy-efficient operation |
